Veterinary Ultrasound Scanner MSU1 PLUS

1.982,64 excl. VAT

Veterinary Ultrasound Scanner MSU1 PLUS

SKU: USN19001 Category: Tags: , , , ,


Veterinary Ultrasound Scanner MSU1 PLUS

The Veterinary Ultrasound Scanner MSU1 PLUS from KaiXin, thé ultrasound expert, is an economical veterinaire Ultrasound Scanner. It is fully digital, mechanical sector scanner to be used for sheep, dog, cat, goat, pigs and the like. Can also be used for somewhat bigger animals like cow and horse but there will be degradation of the picture due to the limitations of the probe. For these bigger animals it is advisable to use the more expensive Ultrasound Scanners which allow the use of specialized probes.

– Pregnancy tests
– Backfat measurements
– Compact and lightweight
– Waterproof, dustproof
– Net Weight 1.1 Kg
– Main Unit Dimensions: 155x180x80 (LxWxH)
– Batteries will last for >200 minutes
– 5.7″ high resolution color LCD

Primary Functions:
– Mode conversion function.
– Magnification conversion function.
– Frequency conversion function.
– Frame correlation function.
– Image post-process function.
– Image freeze/unfreeze function.
– Depth range selection function.
– Pseudo color display function.
– Local zooming function.
– Adjustment of near field, far field, total gain and dynamic range.
– Image storage function.
– Image up/down, left/right reverses function.
– Case information, image annotation and auto time display.
– Body marks.
– Measurement of distance, circumference, area, volume, slope, heart rate and cycle.
– OB software package including 17 obstetric tables about 5 kinds of animals,
automatic calculation of GA and EDC.
– Puncture guide line and lithotripsy positioning line.
– PAL-NTSC Conversion.
– Energy saving.
– Obstetric report.

Additional information

Weight 1,1 kg
Dimensions 15,5 × 18 × 8 cm

Specificaties & Manuals

– 5.7″ High resolution color LCD, high brightness, high contrast, wide visual, suitable for outdoor use.
– Body mark: 1) general cardiac 2) bovine 3) canine 4) equine 5) feline 6) Cardiology 7) swine-7 kinds, total 27 body marks with probe position.
– Display mode: B,2B,4B,B/M,M, total 5 kinds.
– 5 kinds of Magnification, maximum display depth is 200mm.
– Gain range: 0~127dB
– Dynamic range: 27~90dB
– Gray: 256
– Frame frequency: 30 frames/second
– Pseudo-color: 8 kinds (incl. B/W)
– Local zoom and local additive color.
– Permanent image storage: 100 frames.
– Puncture guiding function, (2 guiding lines, angle and position adjustable).
– General measurement: distance,Perimeter, area (trace method, ellipse method), volume, etc.
– Cardiac measurement: depth, slope, heart rate, time.
– OB measurement: EDD and GA for Bovine, equine, ovine, canine, feline, goat, swine and llama.
– OB report function.
– Adapter rating: 100-240V, 50-60Hz,1.2A.
– Output of adapter: DC12.8V 3.0A.
– Battery: 1pc of high-capacity lithium Battery(2400mAh) ,more than 200 minutes work.
– Net weight: 1.0kg.
– Main unit size: 155x180x80mm (length x width x height)
– Warranty: Main Unit 2 years, Probe 6 months

– Main unit + one 3.5MHz waterproof mechanical sector probe;
– Power adapter, Lithium battery, Leather case, Base Charger, Belt, Bracket, Shutter release.

Video glasses, USB flash disk, Mouse, Video printer, Battery, Black suitcase, Color laser printer

The Manual of the Veterinary Ultrasound Scanner MSU1 PLUS from Kaixin can be studied here:
KaiXin Ultrasound Scanner MSU1Plus user’s manual V1.01


1. “Guaranteed Uptime” Contract
This product can be offered with a “guaranteed uptime” contract. With this contract the customer is guaranteed to remain in full operation.
Equip4Vets will keep the same or a similar (same functionality) in our store, available as replacement in the event that the original product refuses proper operation.
Please request the T&C and our attractive pricing schedule.

2. “Lease” Contract
This product can also be “leased” for 3 years. After the 3 years there will be a transfer of ownership from Equip4Vets to the customer.
Please request the T&C and our attractive pricing schedule.
