Veterinary Ultrasound Scanner K10 Full Digital B Mode

2.999,173.652,07 excl. VAT

Veterinary Ultrasound Scanner K10 Full Digital B Mode

Description

Veterinary Ultrasound Scanner K10 Full Digital B Mode

The Veterinary Ultrasound Scanner K10 Full Digital B Mode is one of the new B Mode Ultrasound Scanners from Kaixin, thé ultrasound scanner expert. It is still also a top range ultrasound scanner for the professional! B Mode Ultrasound Scanner with an excellent price/performance. This Veterinary Ultrasound Scanner K10 Full Digital B Mode was developed to cover a broad range of examinations, among others pregnancy, fertility research as well as several diagnosis such as abdomen, cardio, OB, small parts, vessels…etc, and applicable for small as well as big animals.
It is offered with the opportunity to use several probes, each for their own research domain. and for different animals.

Features:
– 10.4″ LCD display
– With high quality image resolution & powerful veterinary software package.
– B mode ultrasound and backfat measuring function two-in-one, which can meet veterinarians’ most daily demands.
– A mode ultrasound gets accurate backfat and lean rate measurement.
– TV/VGA/Freeze, three-in-one, easy to operate.
– 10 kinds grid for quick measurement, make the diagnosis more efficient.
– 6 kinds of operation backgrounds for different visual habits.
– 5.8GHz RFID connection with external wireless monitor for display under real time, facilitate information sharing and remote consultation.
– Wifi connection with Android system Phone/Pad and PC ultrasound working station to get image & data transfer & management easily.
– OB record:detailed record the diagnosis results.
– Diagnosis List: record diagnosis quantity, easy for batch management.

Standard Configuration:
– Main unit 1PC
– 6.5MHz multi-frequency micro-convex probe 1PC
(5.0/6.5/7.5/9.0 MHz)

– Power supply adapter 1PC
– Li-battery 1PC
– Suitcase 1PC
– Drive-by-wire switch 1PC
– Information card 1PC

Optional:
– Optional probes
– 6.5MHz linear rectal probe (4.5/5.5/6.5/7.5 MHz)
– 3.5Mhz loin muscle linear probe (2.0/2.5/3.5/5.0 MHz)
– 3.5MHz convex probe (2.0/2.5/3.5/5.0 MHz)
– 7.5MHz linear probe (6.0/6.5/7.5/9.0 MHz)
– 4.0MHz convex rectal probe (2.0/2.5/4.0/5.0 MHz)

Additional information

Weight 2 kg
Dimensions 26,9 × 4,0 × 26,6 cm
Probe

std 6.5MHz micro-convex, 3.5MHz convex abdomen, 6.5MHz linear rectal, 7.5MHz high freq linear, 3.5MHz loin muscle linear, 4.0MHz convex rectal

Specifications & Manuals

Short Technical Specification:
– Scanning mode:electronic convex & linear
– Mode:B、B/B、B/M、M、A
– Main frequency:3.5/6.5/7.5MHz
– Measurement:distance, area, OB, backfat, lean rate, etc
– Battery driving time:about 4 hours
– Dimension:269×40×266 (mm,L×W×H)
– N.W:2 kg
– Wifi type:802.11g/20MHz/2.4G
– APP support: Android、Windows
– Vector:PAD/Phone/PC
– Warranty main unit + probes 3 years, batteries and accessories 1 year

The Leaflet of KaiXin’s K10 Full Digital B Mode Ultrasound Scanner can be found here:
KaiXin K10 Veterinair Full Digital B Mode Ultrasound Scanner leaflet

A detailed Manual of the Veterinary Ultrasound Scanner K10 Full Digital B Mode can be studied here:
KaiXin Ultrasound Scanner K10 User’s manual V1.01

Add-ons

1. “Guaranteed Uptime” Contract
This product can be offered with a “guaranteed uptime” contract. With this contract the customer is guaranteed to remain in full operation.
Equip4Vets will keep the same or a similar (same functionality) in our store, available as replacement in the event that the original product refuses proper operation.
Please request the T&C and our attractive pricing schedule.

2. “Lease” Contract
This product can also be “leased” for 3 years. After the 3 years there will be a transfer of ownership from Equip4Vets to the customer.
Please request the T&C and our attractive pricing schedule.
